Tc Task Get

Optional.This Snap has at the most one document input view.

The required input of the snap is the inbox where tasks shall be loaded from.

• Mapper
• Copy

This Snap has exactly one document output view.

The output of the snap is the task objects stored in defined inbox as a result list.

• Mapper
• Router

Default value: Tc Task Get

Inbox to get tasks from. Dropdown offers three possibel selections:

• Tasks To Perform
• Tasks To Track
• Both

Default value: Tasks To Perform

Example: Tasks To Perform

User to get tasks for. If empty current user is used. Suggestion offers a list of installed users from your Teamcenter.

Default value: N/A

Example: User111

ID of resource pool user has subscribed to.

Default value: N/A

Define if task for a (single) target shall be searched for only.

Default value: Unselected

Example: Unselected

Appears when Filter tasks is selected.

Select the UID (unique identifier) or the Teamcenter adapter ID of the target object tasks shall be filtered for.

Default value: N/A

Appears when Filter tasks is selected.

Define if amount of objects in result is 1 or more. If checkbox is selectect and more then one object is found, error will be thrown.

If checkbox is unselected response contains JSON list element „result“ including all found object(s).

Default value: Selected

Example: Selected

Select this checkbox to make the Snap look for the name given in Expand Attributes Path in the input document (for example, $expand) or in the Pipeline parameters (for example, _expand), and use that content. Expand Attributes Path then changes to a String field with the default value $.expand. In Pipeline parameters, separate the attribute names with commas.

When deselected, configure Expand Attributes Path as a string or an expression.

Default status: Deselected

Specify the JSON path to the expand attributes in the input document. Expand attributes are the list of attributes that the Teamcenter response must contain. Each name must be the technical name of a valid property in the Teamcenter data model for the expected objects. For example:

"expandAttributes": [
  "item_id",
  "item_revision_id",
  "last_mod_date",
  "object_string",
  "items_tag.uom_tag"
]

Learn more: Configuring Expand Attributes.

Default value: N/A

Example: $.expandAttributes

Select how the Snap represents references and lists of values (LOVs) that Teamcenter returns. The Snap can return them as nested JSON objects instead of flattened IDs and internal values with additional _DISPLAY attributes:

• References become {"_id": …, "UID": …, "_display": …} or null, including inside reference arrays.
• LOVs become {"_value": …, "_display": …} or null, including inside LOV arrays.

The available options are:

• Yes. The referenced object or LOV is a separate JSON object in the result. For example:

  "owning_user": {
    "_id": "TC*User*null***AgKAUUYTZLWoZA",
    "object_string": "user111 (user111)",
    "UID": "AgKAUUYTZLWoZA"
  }

• No. The referenced object or LOV is flattened into attributes on the current result object, and synthetic attributes such as those ending in _DISPLAY are added. For example:

  "owning_user": "TC*User*null***AgKAUUYTZLWoZA",
  "owning_user_DISPLAY": "user111 (user111)"

• Use Default. The Snap uses the default configured for the Snap Pack, which is Yes or No depending on the adapter.tc.snaplogic.expandReferencesAndLovs setting in the teamcenter_snappack.properties file.

Default value: Use Default

Example: Yes
