Tc Product Configurator Structure Get

Optional.This Snap has at the most one document input view.

The required input of the snap is the PDC Object created/already existing in Teamcenter.

• Mapper
• Copy

This Snap has exactly one document output view.

The output of the snap is the PDC object and its structure from Teamcenter.

• Mapper
• Router

Default value: Tc Product Configurator Structure Get

Select the UID (unique identifier) or the Teamcenter adapter ID of the object.

Default value: $._id

Example: QKGAAAuAbq612C

UIDs in Teamcenter are as the name says UNIQUE. The UIDs in the example only exist in our Teamcenter system as expected for our example. Same is valid for Adapter ID "_id" since its base is the UID.

Specify the revision rule that you want the Snap to use for the structure expansion.

Default value: N/A

Example: Latest Working

Select checkbox to configure date or effectivity dates to get revision rule instead of ootb „most recent“ date.

Default value: Selected

Example: Selected

Define date format for next field Date.

Default value: yyyy-MM-dd HH:mm:ss

Example: yyyy-MM-dd

Define date of Revision Rule.

Default value: N/A

Example: 2022-01-01

Define Effectivity In Date of revision rule.

Default value: N/A

Define Effectivity Out Date of revision rule.

Default value: N/A

Activate checkbox to get variants information in response.

Default value: Deselected

Example: Selected

Activate checkbox to extract variant information based on rule texts for variants.

OFF: Extraction of variants is done as the default behavior of the SOA Service provides it.

ON: Manual rule text evaluation leads to extraction of families, groups etc. relevant for current variant.

Default value: Selected

Example: Selected

Select this checkbox to make the Snap look for the name given in Expand Attributes Path in the input document (for example, $expand) or in the Pipeline parameters (for example, _expand), and use that content. Expand Attributes Path then changes to a String field with the default value $.expand. In Pipeline parameters, separate the attribute names with commas.

When deselected, configure Expand Attributes Path as a string or an expression.

Default status: Deselected

Specify the JSON path to the expand attributes in the input document. Expand attributes are the list of attributes that the Teamcenter response must contain. Each name must be the technical name of a valid property in the Teamcenter data model for the expected objects. For example:

"expandAttributes": [
  "item_id",
  "item_revision_id",
  "last_mod_date",
  "object_string",
  "items_tag.uom_tag"
]

Learn more: Configuring Expand Attributes.

Default value: N/A

Example: $.expandAttributes

Select how the Snap represents references and lists of values (LOVs) that Teamcenter returns. The Snap can return them as nested JSON objects instead of flattened IDs and internal values with additional _DISPLAY attributes:

• References become {"_id": …, "UID": …, "_display": …} or null, including inside reference arrays.
• LOVs become {"_value": …, "_display": …} or null, including inside LOV arrays.

The available options are:

• Yes. The referenced object or LOV is a separate JSON object in the result. For example:

  "owning_user": {
    "_id": "TC*User*null***AgKAUUYTZLWoZA",
    "object_string": "user111 (user111)",
    "UID": "AgKAUUYTZLWoZA"
  }

• No. The referenced object or LOV is flattened into attributes on the current result object, and synthetic attributes such as those ending in _DISPLAY are added. For example:

  "owning_user": "TC*User*null***AgKAUUYTZLWoZA",
  "owning_user_DISPLAY": "user111 (user111)"

• Use Default. The Snap uses the default configured for the Snap Pack, which is Yes or No depending on the adapter.tc.snaplogic.expandReferencesAndLovs setting in the teamcenter_snappack.properties file.

Default value: Use Default

Example: Yes

ON: Policy is built dynamically using the expand attributes for rules to inprove performance.

Default value: Selected

Example: Selected

Select this checkbox to make the Snap look for the name given in Expand Attributes Path in the input document (for example, $expand) or in the Pipeline parameters (for example, _expand), and use that content. Expand Attributes Path then changes to a String field with the default value $.expand. In Pipeline parameters, separate the attribute names with commas.

When deselected, configure Expand Attributes Path as a string or an expression.

Default status: Deselected

Specify the JSON path of the expand attributes in the JSON input document. Expand attributes are a list of attributes the response from Teamcenter shall contain. In JSON document the content for path can look like this:

"ruleExpandAttributes": [
            "object_string"
        ]

Names in list have to be technical names of valid properties in Teamcenter datamodel for the expected objects.

Default value: N/A

Example: $.ruleExpandAttributes

Select how the Snap represents references and lists of values (LOVs) that Teamcenter returns. The Snap can return them as nested JSON objects instead of flattened IDs and internal values with additional _DISPLAY attributes:

• References become {"_id": …, "UID": …, "_display": …} or null, including inside reference arrays.
• LOVs become {"_value": …, "_display": …} or null, including inside LOV arrays.

The available options are:

• Yes. The referenced object or LOV is a separate JSON object in the result. For example:

  "owning_user": {
    "_id": "TC*User*null***AgKAUUYTZLWoZA",
    "object_string": "user111 (user111)",
    "UID": "AgKAUUYTZLWoZA"
  }

• No. The referenced object or LOV is flattened into attributes on the current result object, and synthetic attributes such as those ending in _DISPLAY are added. For example:

  "owning_user": "TC*User*null***AgKAUUYTZLWoZA",
  "owning_user_DISPLAY": "user111 (user111)"

• Use Default. The Snap uses the default configured for the Snap Pack, which is Yes or No depending on the adapter.tc.snaplogic.expandReferencesAndLovs setting in the teamcenter_snappack.properties file.

Default value: Use Default

Example: Yes

Select this checkbox if you want the Snap to specify the configuration of the Teamcenter properties for rules in the output. Learn more about configuring output.

Default value: Unselected

Example: Selected

Appears when Configure output for Rulesis selected.

Teamcenter Data Model Type suggestion for Expand Attributes searches attributes for.

Select this checkbox if you want the Snap to create a policy for rules based on expand attributes dynamically.

Default value: Selected

Example: Selected
